Double Cartridge

Mechanical Seal

Overview

Double Cartridge Seal are Recommended for Clean and dirty media application Seal can tolerate reversal pressure. Double Cartridge Seal is Standard for using where Corrosive Liquid are being Processed. These seals are independent of direction of rotation, pre assembled cartridge unit easy to install with different PCD’s pumps due to slots provided on gland plate and these seals can be offered in balanced and unbalanced configuration. Hydrexa  are the top manufacturer of Double Cartridge Seal in INDIA.

Double Cartridge Mechanical Seals are self cartridge units consisting of a shaft, sleeve, seal and gland plate. The unit is fitted on to the pump shaft as a built assembly, and no further fitting is required. They are supplied with various tapings to provide for flashing, cooling water injection and disaster control. The setting position of the seal is set by the cartridge design but the seal unit should not be screwed to the shaft.

double cartridge mechanical seal

TYPE : HI-DCS200

Oparating Limits

Shaft Dia 20mm to 100mm (0.75" to 4")
Pressure 12 bar
Temperature -20°C to 200°C
Shaft Speed 2900 RMP (max)

Material of Construction

  • Seal Faces : Carbon, Sic, Ceramic, TC
  • Secondary Seal : EPR, Viton, Silicon, PTFE, Nitrile, Kalrez
  • Metal Components : SS 316, SS 304, Hast-C, Alloy-20

Characteristics

  • Cartridge Dual Balance & Unbalance Design
  • Inside Mounted
  • Easy Installation

Your Partner for Quality Sealing Solutions.

Ask The Experts

Application

  • Water Solvents
  • Power
  • General Chemicals
  • Pharmaceutical
  • Light hydrocarbon
  • Clear Liquids
